Product Introduction

Product Introduction: Prepainted steel coil or color-coated steel coil is a product made on a continuous production line by coating a cold-rolled coil, galvanized coil, etc. as the base material with one or several layers liquid paint after surface pre-treatment (degreasing and chemical treatment) and baking and cooling. It is characterized as light weight, good appearance, and excellent corrosion resistance, and can be directly processed.

Product details

description

Product Introduction: Prepainted steel coil or color-coated steel coil is a product made on a continuous production line by coating a cold-rolled coil, galvanized coil, etc. as the base material with one or several layers liquid paint after surface pre-treatment (degreasing and chemical treatment) and baking and cooling. It is characterized as light weight, good appearance, and excellent corrosion resistance, and can be directly processed. The colors are regularly white grey, blue, and medium grey. It is mainly used in the advertising industry, construction industry, household appliance industry, furniture industry and transportation industry.

Aoguan factory regular colors: sea blue, white grey, medium grey Factory regular PPGI products are available in stock in various sizes. Customizable colors include orange, sky blue, crimson, brick red, ivory white, porcelain blue etc. The paint used depends on the different usage environments, such as PE, HDP, SMP, PVDF, etc. Customers can choose according to their usage.

Prepainted Steel Coil

parameters
product brand AOGUAN Product Specifications 0.13-1.2mm,customizable
Substrate thickness range 0.13mm-1.5mm Width range 800mm-1300mm
Coil weight range 4-5tons/roll Inner diameter 508mm-610mm
Inner diameter 15g-120g Painting thickness range 15um-50um
performance

01 Good durability, corrosion resistance, and longer lifespan than galvanized coil;

02 Good heat resistance, and is less likely to change color at high temperatures compared to galvanized coil;

03 Similar processing performance and spraying performance with galvanized coil;

04 Good welding performance;.
